Perlan 140 wood

Perlan 140 wood wall installation * Sliding door fitting system for timber, plastic, or metal doors with a leaf weight of 140 kg and wall installation

Perlan 140
  • Sliding door fitting for leaf weights of up to 140 kg
  • For leaves made of wood, plastic, or metal
  • With damping on one or both sides for doors with up to 80 kg leaf weight, so that the door is quietly slowed down and moved into the end position
  • Adjustable wall brackets balance out uneven masonry and allow for a freely selectable clearance from the wall
  • Precision ball bearings in the roller carriages offer very smooth sliding action
  • Tested in accordance with DIN EN 1527 over 100,000 test cycles for durability
Show more
  • Retractable suspension plates allow for the door to be installed with a small clearance between the track and the upper edge of the door
Contact us

Application Areas

  • Frequently used interior sliding doors
  • Living, office, and conference areas as well as hotels
  • Installation of fittings in all visible areas
  • Single and multiple-leaf sliding doors
  • Installation in front of the wall

Technical data

Perlan 140 wood wall installation
Leaf material Wood
Leaf weight (max.) 140 kg
Number of leaves 1-leaf, 2-leaf
Leaf width (min.) 500 mm
Leaf width (max.) 1640 mm
Track geometry straight
Corrosion protection class 2
Type of installation Wall
DIN direction left / right
